Hide & show arguments

A long arg list gets unwieldy fast. CommandRunner lets you mark individual arguments as hidden, they vanish from the visible card list but still get values passed to Run.

Collapsed: Path and Tint visible, then a "+ Hidden (2)" toggle at the bottom

Expanded: clicking "− Hidden (2)" reveals the Log and Notes cards above the toggle

Hiding an argument​

Right-click any argument card → Hide Argument. The card disappears from the visible list. A ▸ Hidden (N) toggle appears at the bottom of the args panel showing how many cards are hidden.

Showing it again​

Click the ▸ Hidden (N) toggle to expand the hidden section. The hidden cards appear directly above the toggle. Right-click any of them → Show Argument to bring it back into the visible list.

What hiding does NOT change​

  • The argument's value is still in arguments.<key> (and props.Arguments.<key>) when Run fires.
  • Per-argument Run callbacks still fire on value changes.
  • Presets still capture and restore hidden arguments.
  • The argument still occupies a row in the auto-generated Types.ArgumentResult type.

Hiding is purely cosmetic, a UI declutter, not a way to disable functionality.

Storage​

Hidden state is stored on two attributes of the command ModuleScript:

  • __HiddenArgs, JSON-encoded array of argument ids that are hidden.
  • __HiddenSectionExpanded, boolean for whether the toggle is currently expanded.

Both persist across plugin reloads and Studio restarts. They're per-place (don't travel through the Library).

When to hide vs. when to remove​

Hide an argument when it's:

  • A power-user knob most users don't need.
  • Only relevant in edge cases (e.g. a debug switch).
  • Configured once and rarely revisited.

Remove an argument from Arguments entirely when:

  • It's no longer used by Run.
  • The schema has changed and the argument is genuinely deprecated.

If you remove an argument from the schema, CommandRunner sweeps the corresponding attribute (and __InstanceArg_* ObjectValue, if applicable) on the next setArguments reconcile. No leaking state.
